Teddy T10

Teddy T10

Supply

  • Static white 500mA
  • Dim warm 400mA

Power

  • 9W

Photometrics

F451

15°

F452

24°

F453

36°

F454

60°

Color Temperature / Luminous flux

2400K 770lm
2700K 1125lm
3000K 1180lm
3500K 1195lm
4000K 1178lm
DW 667lm
875lm

Download

An adjustable projector designed for trimless installations; featuring a minimalist design and superior optical performance. Ideal for both accent and general lighting applications. The Teddy range has field changeable optics and can hold up to two media accessories; including anti-glare filter and a customizable color corrective gel.

Code

Build your code by choosing each attribute

  • TYT10
  • -
  • -
  • -
  • Copy Code
  • Teddy T10

Finish

Beam angle

Cct

Accessories

AT064RO1045

Airtight recessed housing for insulated ceiling

IC064RO1045

Recessed housing for insulated ceiling

LH04

Low luminance hex louvre

MP-R045

Baseplate

RO1045

T-bar baseplate

ZQC001

Plasterboard recessing frame

ZQC001-BMK-WH

White backmount frame for hard surfaces

ZQC001-BMK-BLK

Black backmount frame for hard surfaces

ZQC001-BMK-CU

Custom finish backmount frame for hard surfaces

GEL45

Colour corrective poly gel for Teddy 10 range - consult with factory

OPT4515

Field changeable optic for Teddy 10 range - 15°

OPT4524

Field changeable optic for Teddy 10 range - 24°

OPT4536

Field changeable optic for Teddy 10 range - 36°

OPT4560

Field changeable optic for Teddy 10 range - 60°

Drivers

Static white 500mA

CCPRO10A-500

PHASE / 0-10V(1..1)

10W

CCPRO40A-500

PHASE / 0-10V(1..3)

40W

Dim warm 400mA

CCPRO10A-400

PHASE / 0-10V(1..1)

10W

CCPRO40A-400

PHASE / 0-10V(1..3)

40W

Code X

Build your code by choosing each attribute

Finish

Beam angle

Cct

  • TYT10
  • -
  • -
  • -
  • Copy Code
  • Teddy T10

Accessories +

AT064RO1045

Airtight recessed housing for insulated ceiling

IC064RO1045

Recessed housing for insulated ceiling

LH04

Low luminance hex louvre

MP-R045

Baseplate

RO1045

T-bar baseplate

ZQC001

Plasterboard recessing frame

ZQC001-BMK-WH

White backmount frame for hard surfaces

ZQC001-BMK-BLK

Black backmount frame for hard surfaces

ZQC001-BMK-CU

Custom finish backmount frame for hard surfaces

GEL45

Colour corrective poly gel for Teddy 10 range - consult with factory

OPT4515

Field changeable optic for Teddy 10 range - 15°

OPT4524

Field changeable optic for Teddy 10 range - 24°

OPT4536

Field changeable optic for Teddy 10 range - 36°

OPT4560

Field changeable optic for Teddy 10 range - 60°

Drivers +

Static white 500mA

CCPRO10A-500

PHASE / 0-10V(1..1)

10W

CCPRO40A-500

PHASE / 0-10V(1..3)

40W

Dim warm 400mA

CCPRO10A-400

PHASE / 0-10V(1..1)

10W

CCPRO40A-400

PHASE / 0-10V(1..3)

40W
